high speed wire cutting machine cnc

FOB Reference Price:Get Latest Price
$6,000.00 - $12,000.00 / Sets | 1 Set/Sets (Min. Order)
Model Number:
DK7745
Report Suspicious Activity
Overview
Quick Details
Condition:
New
CNC or Not:
CNC
Place of Origin:
Jiangsu, China
Brand Name:
BENYUE
Voltage:
380V/50Hz
Power(W):
1200W
Dimension(L*W*H):
1560x1200x1700mm
Certification:
ISO9001
After-sales Service Provided:
Engineers available to service machinery overseas
working table size:
950mmx580mm
travel of working table:
450mmx650mm
Maximum cutting thickness:
300mm
Taper machining:
3-6°/80mm
Maximum load weight:
750kg
Optimum surface roughness:
Ra<2.5um
Series:
DK7745
Type:
high speed
Color:
blue and white
Weight:
1600kg
Supply Ability
Supply Ability:
150 Set/Sets per Month
Packaging & Delivery
Packaging Details
wooden container
Port
Shanghai

HIGH

SPEED WIRE

CUTTING EDM

DETAILS

TAPER

MEASURING HEAD

Small taper adjustment device, the

largerst taper adjustable to 6°/80mm

CONTROL PANEL

It seems simple and clear ,use-friendly

control.

MOVEMENT

WIRE SYSTEM

Use stainless steel surface , long

service life.

WORKBENCH

It's a flexible processing auxiliary

equipment which suitable for all kinds

of shapes.

Electric system

All the parts are made of brand

products,quality assurance, low

failure rate.

wire edm machine  -- Parameter:



ModelWorking table sizeTravel of working tableMaximum cutting thicknessTaper machiningMaximum load weightOptimum surface roughness
DK7725400x579mm250x320mm300mm3-6°/80mm300kgRa<2.5um
DK7732680x440mm320x400mm400-500mm3-6°/80mm400kgRa<2.5um
DK7735740x470mm350x450mm500mm3-6°/80mm450kgRa<2.5um
DK7740760x540mm400x500mm400-500mm3-6°/80mm600kgRa<2.5um
DK7745920x540mm450x630mm400-500mm3-6°/80mm750kgRa<2.5um
DK77501147x655mm500x800mm600-800mm3-6°/80mm800kgRa<1.0um
DK77631380x800mm630x1000mm600-800mm3-6°/80mm2000kgRa<2.5um
DK77801600x1000mm800x1200mm400-800mm3-6°/80mm1500kgRa<2.5um
DK771001820x1180mm1000x1400mm1000mm3-6°/80mm4000kgRa<2.5um
DK771201340x2000mm1200x1600mm600-1000mm3-6°/80mm7000kgRa<2.5um







    workpiece

    wire edm machine  -- Optional:

     1.Taper cutting appliance. (±3°, ±30°)

     2.Straight guide rail

     3.Protective cover

     4.high speed controlling system

     5.medium-feeding wire controlling system

     6.integrated machine appliance

     7.autocut system,HL system,WinCut system,HF system

     8.DK77 Series can choose the Cutting Magnets

     9.DK77 Series can choose the Cutting Aluminium



     Features of the cnc wire cut edm machine:



      Special supporting design of the machine with high strength and heavy loading capacity.

     The machine uses the V-shape long span and long guiding rail structure lined with steel which helps the stability.

     The feeding wire part of the machine uses the driving system of gearwheel with lower noise and longer life.

     The maximum diameter of molybdenum wire is <= 0.25mm. The wire tube uses the chroming material with good

     wear resistance.

     The cutting accuracy of all direction is less than 0.01mm. Use high precision ball screw, which has high

     transmission efficiency,

     good positioning accuracy, long life and well synchronization performance. Use the high precision guide rail with

     high strength, heavy loading capacity and low resistance. High stability of the machine. The failure rate is almost 0.

     Apply beakless soft reversing, which prolongs the service life of reversing key. All the machine applies the high

     precision guide wheel appliance to enhance the accuracy of cutting. All the machine-tools use the laser

     interferometer to test the accuracy. (Renishaw Laser Test System from the great Britain).

PLYWOOD PACKING
